Telemecanique Altivar 58 manual
Hello ,
You can find below Schneider Electric (Telemecanique) ATV 58 variable speed drive user manual and catalogue.
What is Telemecanique Altivar 58 VFD?
The Telemecanique Altivar 58 is a variable frequency drive (VFD) designed for controlling the speed of three-phase asynchronous motors. It's a compact, high-performance drive that offers advanced control and protection functions, as well as a range of communication options. It can be used in a variety of applications such as pumps, fans, conveyors, and other industrial machinery. It also offers energy savings solutions, and allows you to purchase only the performance you need, saving on initial purchase cost and setup time. The drive also has a user-friendly interface, with a large keypad and backlit LCD display, which provides real-time operational data.
The Telemecanique Altivar 58 TRX is an advanced version of the Altivar 58 variable frequency drive (VFD) designed for controlling the speed of three-phase asynchronous motors. It is a Transparent Ready™ product that offers extended functionality and an extended horsepower range up to 500 hp. It includes an analog output, expanded firmware capabilities, and it can be configured, controlled, monitored, and diagnosed over an Ethernet network using a standard web browser, without the need for special software or drivers. The ATV58 TRX controllers accept all of the current I/O options, communication card options, and hardware options. The ATV58 TRX family drive controllers range from 1-75 hp (0.75-55 kW) constant torque, 400/460 V, three-phase input to 1-500 hp (0.75-315 kW) variable torque 400/460 V, three-phase input, 0.5-7.5 hp (0.37-5.5 kW) constant torque, 208/230 V, single-phase input to 0.5-30 hp (0.37-22 kW) variable torque, 208/230 V, single-phase input, and 2-40 hp (1.5-30 kW) constant torque (50 hp variable torque), 208/230 V, three-phase input.
The Telemecanique Altivar 58 TRX is available in a range of horsepower ratings, from 125-500 hp, and is listed in instruction bulletin VVDED397048US. These drive controllers are typically used for variable torque applications such as fans and pumps, but with proper selection, they can also be used in constant torque applications like compressors, conveyors, and extruders where high performance is not required at low speeds. The product ratings for the 125-500 hp range are for applications that require 100% rated torque down to 6 Hz. If the application requires more than 110% transient torque for one minute, you need to select the appropriate horsepower product. For assistance with selecting the proper AC drive controller for constant torque applications, consult your local Square D drives specialist. Application information is also available in product data bulletin SC100, Adjustable Frequency Controllers Application Guide available at www.SquareD.com or in the NEMA Standards Publication: Application Guide For AC Adjustable Speed Drive Systems.
